Chemistry: LFP
Nominal Voltage: 51,2V
Voltage Range: 47,5V – 57,6V
Nominal Current: 100Ah
Nominal Capacity: 5,12 kWh
Unit Dimension: L440mm x W530mm x H140mm (3,2U)
Unit Weight: 44kg
Maximum Charge Current: 100A
Recommended Charge Current: 75A
Maximum Discharge Current: 100A
Recommended Discharge Current: 75A
Round-Trip Efficiency: >95%
Communication Protocol: RS485 – CAN – WiFi (W/ Optional Device)
Cycle Life: >6000
Warranty: 10 years
Charge temp: 0°C – 45°C
Discharge temp: -10°C – 50°C
Connect style: Parallel
Heating system: 8 – 10°/Hour
Storage Temperature: 20°C – 35°C
Power Terminal: Amphenol SurLok Plus
